NXP has combined short-range 6 – 8.5GHz UWB radar, secure ranging and angle-of-arrival processing on a single chip. Called SR250, it is for “a world that anticipates and automates, enabling a variety of new user experiences based on location, presence or motion detection across consumer or industrial IoT applications”, claimed the company. It is said to support 3D angle-of-arrival and ...

Toshiba is developing an interface IC for the automotive CXPI (clock extension peripheral interface) bus whose hardware logic “can control data communication by CXPI protocol and GPIO, eliminating the need for dedicated software development”, according to the company. Not a lot more has been revealed about the function of the IC, called TB9033FTG, except that it has 16 GPIO pins, ...

Distributor Rutronik has added three surface-mount RTK-enhanced GNSS modules from Unicore to its portfolio. RTK – ‘real time kinematics’ – is a service that increases the accuracy of satellite navigation systems. UM982 GPS L1/L2/L5 BDS B1I/B2I/B3I GLONASS G1/G2 Galileo E1/E5a/E5b QZSS L1/L2/L5 SBAS 16 x 21 x 2.6mm UM980 BDS B1I/B2I/B3I/B1C/B2a/B2b GPS L1/L2/L5 GLONASS L1/L2 Galileo E1/E5a/E5b QZSS L1/L2/L5 SBAS ...

Diodes has introduced a 12-channel constant-current LED driver arranged as four channels of RGB. AL58221 has open-drain outputs that can sink up to 60mA and withstand 24V. Maximum red green and blue currents are set with three resistors, then the individual channels are digitally-modulated to set their brightness. To reduce flicker, adaptive pulse density modulation is used, with diodes claiming ...

Toshiba is aiming at air conditioners, air purifiers and pumps with an IGBT-based brush-less dc motor driver, suitable for sine-wave generation, in a ~13 x 33mm through-hole HDIP30 package. TPD4165K, as it will be know, can handle a maximum output of 3A, compared with 2A for the company’s earlier TPD4163K or TPD4164K. Absolute maximum input voltage has been raised to ...

It seems to be Ideal Diode Week at Electronics Weekly (here and here) as Diodes is also promoting one, this time an ideal diode that can cope with ±65V on its input and drops only 20mV when conducting. The automotive-compliant AP74700Q operates down to 3.2V (or 3.9V at start-up) to allow for cold cranking of a vehicle engine. Inside, a ...

Nexperia has put an ideal diode, including its p-channel mosfet, and reverse polarity protection, in a 2.1 x 1.25 x 0.95mm TSSOP6 package. Called NID5100, it is aimed at industrial and consumer applications, and has an automotive-qualified cousin named NID5100-Q100. “NID5100 supports ‘OR-ing’ multiple power supplies while retaining reverse polarity protection and provides fast response time for smooth power transfer,” ...

Infineon has introduced six automotive linear regulators, protected against 40 or 45V, and supplying 3.3 or 5V at up 500mA, some with enable, watchdog or reset circuits (see the table below). Picking the TLS820F3ELV50 as an example, it has an input range of 3 to 42V (45V abs max) and outputs 5V ±2% at up to 200mA. “These regulators are ...

Infineon Technologies is to integrate 600 and 700V GaN power hemts alongside gate driver chips inside single packages, in 5 x 6mm or 6 x 8mm SMD packages. IGI70NxxxA2xS is to be a 700V range that combines a single GaN transistor with a single-channel driver in 5 x 6mm PQFN with with 140 to 500mΩ options (IGI70NxxxA2PS), or 6 x ...

Lumissil Microsystems has created a pair of LED drivers that include a 32MHz 8051 microcontroller. “These new controllers enable lighting engineers to create customised dynamic LED lighting animations tailored to their system requirements,” according to the company. “They feature integrated non-volatile memory to store animation sequences and LED parameters, essential for dynamic lighting effects such as colour transitions, pulsing, fading ...
