Test & Measurement

Pickering Interfaces, has announced a family of one-slot PXI and PXIe programmable resistor modules that can handle 2A, 200V or 15W. Models 40-254 (PXI) and 42-254 (PXIe) come in 28 variants, summarised as: two channel versions with various narrow resistance ranges, and then single channel versions with various narrow, medium or wide resistance ranges. PXI vVersions are compatible with PXI ...

Rohde & Schwarz is looking forward to times when nations mandate radar testing as part of annual vehicle inspections. It has created RadEst, a radar target simulator intended to function in the tough world of vehicle workshops. As well as simulating targets, the unit can measure radar parameters such as EIRP (equivalent isotropic radiated power) and occupied bandwidth. “With an ...

Keysight has introduced a series of 14bit general purpose oscilloscopes with up to 1GHz bandwidth. The HD3 Series is “built from the ground up with a custom asic deep memory architecture”, said the company, while also saying that it is “leveraging custom hardware technology from the UXR Series”. There are two channel and four channel versions, both with 16 digital ...

Juno is a neutrino detector under construction 750m below Jiangmen in China. A collaboration between 17 countries, 730 scientists from 74 universities and national laboratories have worked on it. At its heart will be a 34.5m diameter acrylic sphere filled with 20,000 tons of liquid scintillator, which will emit photons if neutrinos interact with it – neutrinos sourced from eight ...

Tektronix has taken its TAP1500 1.5GHz active single-ended probe, and stretched its 1.3m cable to seven metres “with no loss in performance”, according to the company. TAP1500L is the name of the extended version. “Our customers can’t always have their oscilloscopes close to their device-under-test,” said Tektronix probe manager Andrew Mumford, “and the longer cable benefits customers who use flying ...

Anritsu has created a 9kHz to 54GHz spectrum analyser module that can be added to other test set-ups. MS27200A-0754, as it will be known, has 110MHz real-time analysis bandwidth, where it can can stream and capture IQ in 32bits, and -164 dBm DANL. That said, much of this performance requires options to be purchased and added. “The module is self-contained, ...

Three bench oscilloscopes by Siglent, the SDS800X HD, SDS1000X HD and SDS3000X HD are now available from Telonic Instruments. The high-resolution oscilloscopes address signal fidelity, visualisation, and analysis with 12-bit ADCs, low noise, gain accuracy, and channel isolation, said the company. Bandwidths range from 70MHz to 4GHz, providing signal fidelity for a range of applications including power, EMI, frequency analysis, ...

Rohde & Schwarz is claiming the world’s fastest oscilloscope zone trigger update rate, using a dormant asic feature that can now offer of up to 600,000 waveform/s and has <1.45μs blind time between trigger events. Zone triggering allows users to specify trigger conditions by drawing one or more zone areas on the instrument’s display. Each acquisition is then inspected for ...

Teledyne LeCroy has added lower bandwidth options to its 8000HD range of 12bit oscilloscopes, which now includes models at 6 (8060HD), 8 (8080HD), 13 (8130HD), and 16GHz (8160HD). This bandwidth is available through the physically-smaller 50Ω input connectors, while the BNC connectors offer 2GHz (-3dB) in 50Ω mode and 500MHz in 1MΩ mode. They do not get the 1.8mm coaxial ...

NI has set out its stall for AI in the test industry. Following the announcement of LabView AI assistant at the end of last year (currently in beta testing), CTO of technology and innovation, Kevin Shultz spoke to Electronics Weekly about what will be the role of AI in test. He explained that the increasing complexity of products being tested ...
